T-shirt Bag Automatic Making Machine (4 Lines/2 Print Photo Cell)

T-shirt Bag Automatic Making Machine (4 Lines/2 Print Photo Cell)
FTAA2+P
Video
Model FTAA2 28X30+P FTAA2 32X30+P FTAA2 40X30+P FTAA2 50X30+P FTAA2 60X30+P
Max Cutting Width 12"x4 14"x4 18"x4 23"x4 28"x4
Max Cutting Length 30" 30" 30" 30" 30"
Length Tolerance mm ±1 ±1 ±1 ±1 ±1
Thickness mm 0.01-0.15 0.01-0.15 0.01-0.2 0.01-0.2 0.01-0.2
Prod. Per. Min pc 40-120 40-120 30-100 30-100 30-90
Driving Motor AC 2hp 2hp 2hp 2hp 2hp
Heater Capocity kw 5.1 6.2 7.8 10 11
Power Required kw 6.2 7.5 9 11.5 13
Dimehsion L x W x H cm 350 x 135 x 220
260 x 123 x 166		 350 x 145 x 220
260 x 133 x 166		 350 x 165 x 220
260 x 153 x 166		 350 x 190 x 220
260 x 178 x 166		 350 x 215 x 220
260 x 203 x 166
Machine Weight kg 1100+600 1300+700 1500+80 1800+100 2100+1100
Measurement L x W x H cm 255 x 145 x 225
270 x 133 x 176		 255 x 155 x 225
270 x 143 x 176		 255 x 175 x 225
270 x 163 x 176		 255 x 200 x 225
270 x 188 x 176		 255 x 225 x 225
270 x 213 x 176
Gross Weight kg 1400+800 1600+900 1900+1000 2200+1300 2500+1400
